EWM Phoenix 355 Expert 2.0 puls MM

Produktnummer: 090-005445-00502
inkl. mva.

Multiprocess MIG/MAG pulse welding machine with MULTIMATRIX technology, compact, portable, modular, Expert 2.0 control

  • Compact inverter welding machine with integrated wire feed mechanism
  • Expert 2.0 control with intuitive user guidance via LCD panel and plain text display of all welding parameters and functions
  • Welding procedures and functions
  • Equipped at no extra charge with EWM Synergic characteristics for forceArc, forceArc puls, rootArc, rootArc puls and superPuls
  • Equipped at no extra charge with Synergic characteristics for GMAW welding of steel/CrNi/aluminium
  • Suitable for MMA welding, TIG welding and gouging at no extra charge
  • rootArc –
  • Short arc with good modelling properties for easy gap-bridging and positional welding
  • ForceArc –
  • Low-heat, directionally stable and powerful arc with deep penetration for the upper power range
  • Pulsed arc –
  • Controlled, short circuit-proof pulsed arc for all positions, especially in the transitional arc area
  • Individually configurable programs for each welding task (JOB)
  • Adjustable start and end-crater functions
  • Infinitely adjustable arc dynamics (choke effect)
  • Synergic or manual welding operation
  • Your benefits
  • No need to purchase additional characteristics – all characteristics for this machine type are included in the scope of delivery ex works
  • Gas cooled or optionally water cooled with cool 50 U40 cooling unit
  • High-precision, powerful EWM eFeed 4-roll wire feed mechanism for secure feeding of all solid and flux cored wires
  • Equipped with 1.0–1.2 mm UNI rolls for low to high-alloy steel
  • Wire spool diameter up to 300 mm/D300, 200 mm/D200 possible with adapter
  • High open circuit voltage for excellent ignition characteristics
  • Energy-saving thanks to high efficiency and standby function
  • Connection capability for remote control and function torch
  • Easy, tool-free change of welding polarity
  • Insulated wire space
  • IP23 spray water protected
Merke EWM
Lengde 482.0 mm
Bredde 298.0 mm
Salgsenhet Stk
